• Motor


    TENWAYS C9 Hub Motor (250 W Power, 45 Nm Torque)

  • Sensor

    Torque Sensor

  • Display

    TFT Color Display

  • Battery

    500Wh ( 36 V, 14 Ah ) Lithium-ion Battery

  • Controller

    Vector Sine Wave Controller

PERFORMANCE

  • Top Speed

    25 km/h*

    *The motor will stop giving assist at the stated top speed. You can still ride beyond the stated top speed with pure muscle power. This limit is set in accordance with local regulations.

  • Range

    Up to 100 km*

    *Actual performance will vary depending on temperature, road conditions, rider's weight, etc.

  • Climbing Ability

    Suitable for moderate urban slopes *

    *The actual performance would depend on the rider's physical strength.

COMPONENTS

  • Frame

    6061 Aluminium Frame

  • Crankset

    Gates CDX Crankset

  • Wheels

    20" Aluminium Rims

  • Drivetrain

    Single-speed Drivetrain
    Gates CDN Carbon Belt

  • Brake

    TEKTRO Hydraulic Disc Brakes

  • Tires

    CST Puncture-proof 20" Tires

  • Front Fork

    TENWAYS Alloy Rigid Fork

  • Saddle

    Selle Royal Black

  • Weight*

    Net weight: 19.8 kg (excluding all accessories)
    Full weight: 24 kg (including all accessories)
    MIK HD Rear Carrier, Max. Load: 27 kg
    Permissible Max. Weight: 145 kg

    * All stated weight numbers have a +/- 3%-5% tolerance. Net weight includes the battery but excludes all accessories. Full weight includes the battery and all accessories.

GEOMETRY

SIZE (mm)One Size
A
Effective top tube
/
B
Seat tube length
445
C
Head tube
250
D
Steering angle
71.5
E
Seat tube angle
72
F
Chainstay
442
G
Wheelbase
1081
H
Standover
449
*Specifications are subject to change without notice. In case of unexpected supply-side impacts, we will offer components of equivalent or better capabilities.
FAQ
1.What is the CGO Compact e-bike best for?

The CGO Compact is designed for modern city life—sleek, stylish, and surprisingly capable. It’s perfect for daily commuting, quick grocery trips, school runs, and weekend rides, all while staying easy to store and carry.


Why riders love it:

●Ultra-compact design that saves space

●MIK HD rear carrier for child seats and accessories

●Quiet, low-maintenance Gates Carbon Belt drive

●Smooth, responsive torque sensor for a lively ride

●Built for customization with a wide range of accessories

2.What is the recommended height for riding the CGO Compact?

Thanks to the Byschulz Speedlifter twist stem and refined geometry, the CGO Compact suits a wide range of body heights. Riders between160 cm and 190 cmcan comfortably ride it.

3.Can I use a child seat on the CGO Compact?

Yes. The CGO Compact’s rear carrier is equipped with theMIK HD system, so any child seat compatible with the MIK HD system can be used on the CGO Compact.
